Netgear

Netgear AVLine

Control Netgear AVLine AV-over-IP network switches (M4250, M4300, M4350, M4500).

Configuration

• Enter the switch's management IP and username in the module settings
• The password is stored as a secret and entered separately from the rest of the config
• The connection to the switch's REST API expects the switch's admin account. Other account may be able to log in, but will not be able to run any of the actions.

Actions

• Set POE — enable, disable, or toggle POE on one or more ports. Ports are given as a port (7), a range (2-7), several of either (12-27, 31-33), or all
• Power Cycle POE — as above, for power-cycling POE on a set of ports
• Set Port Enabled — enable, disable, or toggle a physical port
• Set Port VLAN — put a port on a VLAN: untagged (and set as the port's own VLAN), tagged, the port's own VLAN only, or remove it from the VLAN
• Save Configuration — copy the running configuration to the startup configuration, so that changes made by this module (and elsewhere) survive a reboot
• Reboot Switch — restart the switch, optionally saving the configuration first

Feedback

• POE Enabled
• Port Enabled
• Port VLAN
• Link Status

Variables

• active_ports, total_ports
• cpu_usage, memory_usage
• uptime, last_reboot
• device_name, model, serial_number, firmware_version
• fan_state
• poe_budget, poe_total_consumption, poe_main_status, poe_power_management_mode, poe_ports

Per Port Variables

• description, is_poe, admin_mode, access_vlan
• speed, vlans
• rx_mbps, tx_mbps, rx_bytes, tx_bytes
• poe_status, poe_current_power
• lldp_system_name, lldp_port_id, lldp_port_description, lldp_chassis_id

Per Sensor Variables

• temperature_<n>, temperature_<n>_state

Per SFP Module Variables

• sfp_<port>temperature, sfp<port>voltage, sfp<port>_current
• sfp_<port>input_power, sfp<port>_output_power
• sfp_<port>loss_of_signal, sfp<port>tx_fault, sfp<port>_fault_status
• sfp_<port>vendor, sfp<port>part_number, sfp<port>_serial_number

Presets

• POE and Link Status buttons, one per port
• Port Status: a text header per port, followed by read-outs (speed, bandwidth, VLAN, LLDP neighbour, POE draw) and an Enable/Disable button
• Switch Status: a text header, followed by read-outs (model, uptime, CPU, memory, active ports, POE consumption, temperature) and a Save Configuration button
• SFP Modules: a text header per transceiver, followed by temperature, power, and signal read-outs

See the Changelog for what changed in each release.
