Utah Scientific BPS Panel

This module allows you to connect to Utah Scientific routers and controllers that support the RCP3 protocol.

Configuration

Enter the device's IP address
The default port is 5001. Leave this as-is unless you have changed this value on the device.
Enter the number of levels you would like to route.

Actions

Select Source / Destination: This allows for panel-style routing, with am option for "Take on Select", or to use the separate Take action for extra confirmation
Route Source to Destination: one step action, with the ability to choose between all levels or a chosen subset
Set Lock: toggle, lock, or unlock destinations
Toggle / Select / Deselect Levels: Ability to choose specific levels when using the panel-style routing setup

Feedbacks

Selected Source / Destination: highlights selected values; will clear on take
Selected Levels: highlights which levels are selected to be routed
Source Routed to Destination: active when source is routed to selected destination on any selected level
Destination Locked: shows when a destination has an active lock

Variables

source_#_name: Source label assigned by the router or controller
destination_#_name: Destination label assigned by the router or controller
destination_#_source_name: Current source name (level 1 only) for each destination
destination_#_source_id: Current source (level 1 only) for each destination
destination_#_lock_state: Current lock state of each destination
route_#_level#: Active source on each level of each destination
